Common Applications: Micro miniature setups, wire processing, terminations, small connections.

Components:

• 105A3 - 100 Watt Resistance Soldering Power Unit
• 10541 - Regular Tweezer Handpiece
• 10519 - Footswitch

Specifications:

• 100W (2.65VAC) Power unit with Infinitely Variable Output control, Pilot light, 1 AMP Circuit Protection & Heavy-duty aluminum case, Available in 110 or 220V.
• Durable, User-friendly hand piece with four foot (1.22m) AWG 14-2 HPN cord set.
• Copper clad, stainless steel electrodes, 5/64" (1.98mm) Dia., 1-1/2" Lgth. Easily customizable with approx. 3/8" opening upon shipping.
• Rugged, Industrial Footswitch with 6 foot (1.83m), three-wire cord and NEMA 5-15 P/R piggyback plug.

Weight: 5.5LBS (2.475KGS)

Replacement Electrodes: Model # 10542

See Product Data Sheet

Common Applications: Wire processing, terminations, fiber optics, standard connections, electrical, electronics work.

Components:

• 105A12 - 250 Watt Resistance Soldering Power Unit
• 10541 - Regular Tweezer Handpiece
• 10519 - Footswitch

Specifications:

• 250W (2.8VAC) Power unit with Infinitely Variable Output control, Lighted Rocker, 3 AMP Circuit Breaker & Heavy-duty aluminum case, Available in 110 or 220V.
• Durable, User-friendly hand piece with four foot (1.22m) AWG 14-2 HPN cord set.
• Copper clad, stainless steel electrodes, 5/64" (1.98mm) Dia., 1-1/2" Lgth. Easily customizable with approx. 3/8" opening upon shipping.
• Rugged, industrial Footswitch with 6 foot (1.83m), three-wire cord and NEMA 5-15 P/R piggyback plug.

Weight: 9.3LBS (4.185KGS)

Replacement Electrodes: Model # 10542

See Product Data Sheet

Common Applications: Antenna leads and semi-rigid coaxial cable, connections up to 1/4" (6.5mm), heavy gauge wire, terminals, lugs, posts, heavy-duty soldering.

Components:

• 105A12 - 250 Watt Resistance Soldering Power Unit
• 105127 - Medium Tweezer Handpiece
• 10519 - Footswitch

Specifications:

• 250W (2.8VAC) Power unit with Infinitely Variable Output control, Lighted Rocker, Circuit Breaker & Heavy-duty aluminum case, Available in 110 or 220V.
• Durable, User-friendly hand piece with four foot (1.22m) 10 AWG High Strand DLO cord set
• Copper clad, stainless steel electrodes, 1/8" (1.98mm) Dia., 3" Lgth. Easily customizable with approx. 1" opening upon shipping.
• Rugged, industrial Footswitch with 6 foot (1.83m), three-wire cord and NEMA 5-15 P/R piggyback plug.

Weight: 9.7LBS (4.365KGS)

Replacement Electrodes: Model # 10594

See Product Data Sheet

Common Applications: For micro-soldering applications in limited space. Fine AWG wire processing, terminations, very small connections.

Components:

• 105A3 - 100 Watt Resistance Soldering Power Unit
• 105133 - Micro-Tweezer Handpiece
• 10519 - Footswitch

Specifications:

• 100W (2.65VAC) Power unit with Infinitely Variable Output control, Pilot light, 1 AMP Circuit Protection & Heavy-duty aluminum case, Available in 110 or 220V.
• Durable, User-friendly hand piece with four foot (1.22m) AWG 18-2 HPN cord set.
• Stainless steel electrodes, .040" (1.02mm) Dia., 1/2" Lgth. Easily customizable by forming or notching.
• Rugged, industrial Footswitch with 6 foot (1.83m), three-wire cord and NEMA 5-15 P/R piggyback plug.

Weight: 5.5LBS (2.475KGS)

Replacement Electrodes: Model # 105134
