All American Beauty Power Units share the following features;
• Fail-safe devices to ensure ultimate user safety
• Availability in 110/120V or 220/240V varieties
• Can be operated with a variety of handpieces, allowing you to customize resistance soldering to your particular application
• Come with a THREE-year warranty, guaranteeing the product to be free from manufacture defect and to work properly under normal operating conditions.

Reminder: User should adhere to 50% duty cycle rule to ensure handpiece and power unit longevity. (i.e. Use for 10 seconds, rest for 10 seconds)


Included in systems:

• 10501 - Light Capacity Tweezer-Style Resistance Soldering
• 10599 - Micro Tweezer-Style Resistance Soldering System
• 10508 - Light Capacity Single Probe Resistance Soldering System
• 10503 - Standard Capacity Resistance Wirestripping System
• 10503P - Production Capacity Resistance Wirestripping System
• 105SMD - Surface Mount Device Removal System
• 105HCS - Light Capacity Resistance Soldering Hobby System

Specifications:

• Max Output: 100 Watts
• Power Settings: Infinite
• Connections: Taper pins
• Weight: 2.5 LBS (1.1 KGS)
• Dim(in): 3.75"x3.875"x5.25"
• Dim(cm): 9.5 x 9.8 x 13.3
• Color: Black Crackle Finish

Weight: 2.5LBS (1.125KGS)


Included in system:

• 10503P - Production Capacity Resistance Wirestripping System

Specifications:

• Auto On/Off Switching
• Max Output: 100 Watts
• Power Settings: Infinite
• Connections: Taper pins
• Weight: 2.5 LBS (1.1 KGS)
• Dim(in): 3.75"x3.875"x5.25"
• Dim(cm): 9.5 x 9.8 x 13.3
• Color: Black Crackle Finish

Weight: 2.5LBS (1.125KGS)


Included in systems:

• 10502 - Standard Capacity Tweezer-Style Resistance Soldering System
• 10504 - High Capacity Tweezer-Style Resistance Soldering System
• 10506 - Standard Capacity Plier-Style Resistance Soldering System
• 105HCM - Standard Capacity Resistance Soldering Hobby System
• 105HHH - Deluxe Resistance Soldering Hobby System

Specifications:

• Max Output: 250 Watts
• Power Settings: Infinite
• Connections: Taper pins
• Weight: 3.0 LBS (1.4 KGS)
• Dim(in): 3.75"x4.5"x7.125"
• Dim(cm): 9.4 x 11.5 x 18.1
• Color: Black Crackle Finish

Weight: 3.0LBS (1.35KGS)


Included in systems:

• 10507 - High Capacity Plier-Style Resistance Soldering System
• 10509 - High Capacity Single Probe Resistance Soldering System
• 10535 - Medium Electrical Work Resistance Soldering System

Specifications:

• Max Output: 1,100 Watts
• Power Settings: 23
• Connections: Taper pins
• Weight: 6.0 LBS (2.7 KGS)
• Dim(in): 6.5" x 7.5" x 8.5"
• Dim(cm): 16.5x19.1x21.6
• Color: Black Crackle Finish Available with Twist Lock Receptacle

Weight: 6.0LBS (2.7KGS)


Included in system:

• 10505 - Industrial Capacity Plier-Style Resistance Soldering System

Specifications:

• Max Output: 1,800 Watts
• Power Settings: 23
• Connections: Taper pins
• Weight: 30 LBS (13.6 KGS)
• Dim(in): 6.5" x 7.5" x 8.5"
• Dim(cm): 16.5x19.1x21.6
• Color: Black Crackle Finish
• Available w/Twist Lock Receptacle

Weight: 30.0LBS (13.5KGS)


Included in system:

• 10557 - Medium-Duty Resistance Soldering Plumbing System

Specifications:

• Max Output: 1,800 Watts
• Power Settings: 3
• Connections: Ring Terminals
• Weight: 30 LBS (13.6 KGS)
• Dim(in): 8" x 11" x 12"
• Dim(cm): 21 x 28 x 31
• Color: Black Finish
• Requires Model 10518 Footswitch

Weight: 30.0LBS (13.5KGS)


Included in system:

• 10577 - Heavy-Duty Resistance Soldering Plumbing System

Specifications:

• Max Output: 3,000 Watts
• Power Settings: 3
• Connections: Ring Terminals
• Weight: 64 LBS (29 KGS)
• Dim(in): 8" x 11" x 12"
• Dim(cm): 21 x 28 x 31
• Color: Black Finish

Weight: 64.0LBS (28.8KGS)
